Esta subasta ha terminado.
Detalles
Fabricante
TOS KURIM
Tipo
FSQ 100-OR/DI
Año de construcción
1998
Descripción
- metal machining with coolant use
- SIMENS SINUMERIK 840C steering system
- measure system HEIDENHAIN
- max size worked element (without turning of element): H x V x D - 750x1600x1000mm
- max size worked element (with turning of element): H x V x D - 750x800x1000mm
- travel XYZ: 1600x1000x750mm
- max weight of worked element: 4500kg
- advance od 1 do 5000 mm/min
- spindle turning speed range: 11 - 2500/min
- positioning precision to 10µm
- no. of tools in the magazine: 60 pcs.
- max tool lenght: 340mm
- max tool diameter: 130mm
- horizontal/vertical adjustable head
- 2 tables
- table: 1000x1250mm
Machine connected to all media, ready to run.
Full technical and operating documentation aviable.
According to special agreement commission of 15% on selling price will be charged
- SIMENS SINUMERIK 840C steering system
- measure system HEIDENHAIN
- max size worked element (without turning of element): H x V x D - 750x1600x1000mm
- max size worked element (with turning of element): H x V x D - 750x800x1000mm
- travel XYZ: 1600x1000x750mm
- max weight of worked element: 4500kg
- advance od 1 do 5000 mm/min
- spindle turning speed range: 11 - 2500/min
- positioning precision to 10µm
- no. of tools in the magazine: 60 pcs.
- max tool lenght: 340mm
- max tool diameter: 130mm
- horizontal/vertical adjustable head
- 2 tables
- table: 1000x1250mm
Machine connected to all media, ready to run.
Full technical and operating documentation aviable.
According to special agreement commission of 15% on selling price will be charged
Ubicación
- European Community
